Electric Double Helix SiC Heating Elements with 1500℃ Max Service Temp and Customized Size for Industrial Furnaces

Name: Electric Double Helix SiC Heating Elements with 1500 Max Service Temp and Customized Size for Industrial Furnaces
Brand: KEGU
Price: 200 USD

Quality Electric Double Helix SiC Heating Elements with 1500℃ Max Service Temp and Customized Size for Industrial Furnaces for sale

Material : SiC

Composition:SiC : ＞85%

Color : Black

Density : 2.5~2.6g/cm³

Max. Service Temp : 1380℃

Flexural Strength : 70-90 MPa

Size : Customized

Heat Conduction : 23.26 W/(m·℃)

Resistivity : 1000～2000 Ω·mm2/m

Tensile Strength : 39.2～49 MPa

Max. Service Temp. : 1500℃

Linear Thermal Expansion Coefficient (20-1500℃) : 5×10⁻⁶/℃

Electrical Resistivity : 1000~2000Ω·mm²/m

Model Number : Customizable

Brand Name : KEGU

Place of Origin : China

Price : 200-500 yuan/kg

Payment Terms : L/C,D/A,D/P,T/T,,

Supply Ability : 2,000 pcs/month

Packaging Details : Strong wooden box for Global shipping

Contact Now

Electric Double Helix SiC Heating Elements For Electric Furnaces

Silicon Carbide (SiC) heating elements are non-metallic electric heating components manufactured from high-purity green hexagonal SiC crystals generated at temperatures exceeding 2200°C. These elements can operate at temperatures up to 1450°C and provide continuous service for over 2000 hours in vacuum atmospheres without requiring protective gas environments.

Physical Properties

Property	Value	Property	Value
Specific Gravity	2.6-2.8 g/cm³	Bend Strength	>300 kg
Hardness	>9 MOH'S	Tensile Strength	>150 kg/cm³
Porosity Rate	<30%	Radiancy	0.85

Usage Guidelines

Conduct resistance distribution testing before installation to ensure uniform furnace temperature and charge distribution across all elements
Handle with care during installation and maintenance as elements are brittle and susceptible to damage
When starting furnace operation, gradually increase voltage in stages - never apply full load immediately

Electric Double Helix SiC Heating Elements with 1500℃ Max Service Temp and Customized Size for Industrial Furnaces

Required Specifications for Ordering

When ordering Silicon Carbide Heating Elements, please provide the following specifications:

Type
OD: Outer Diameter
HZ: Hot Zone length
CZ: Cold Zone length
OL: Overall Length
Resistance in Ohms (Ω)

Standard Dimensions and Resistance Ranges

OD (mm)	Hot Zone (mm)	Cold Zone (mm)	Overall Length (mm)	Resistance Range (Ω)
8	100-300	60-200	240-700	2.1-8.6
12	100-400	100-350	300-1100	0.8-5.8
14	100-500	150-350	400-1200	0.7-5.6
16	200-600	200-350	600-1300	0.7-4.4
18	200-800	200-400	600-1600	0.7-5.8
20	200-800	250-600	700-2000	0.6-6.0
25	200-1200	250-700	700-2600	0.4-5.0
30	300-2000	250-800	800-3600	0.4-4.0
35	400-2000	250-800	900-3600	0.5-3.6
40	500-2700	250-800	1000-4300	0.5-3.4
45	500-3000	250-750	1000-4500	0.3-3.0
50	600-2500	300-750	1200-4000	0.3-2.5
54	600-2500	300-750	1200-4000	0.3-3.0

Key Features

Withstands temperatures up to 1600°C
High mechanical strength with excellent thermal shock resistance
Noise-free and pollution-free heat source
Superior oxidation and corrosion resistance
Easy installation and maintenance

Ordering Information

Type: rod, U, W, H, spiral, or double-spiral configurations
Dimensions: OD, HZ, CZ, OL
For U or W types, specify terminal distance
Special resistance requirements if applicable
Quantity needed

Applications

Thermoforming & Vacuum Forming Machines
PVC Pipe Belling / Socketing Machines
Hot Stamping Machines
Heat Therapy Equipment
Shrink Packaging Systems

Quality Control
